Svenska我們是專業的康明斯QSK60 發動機檢測報警項目表供應服務商.我們可提供康明斯QSK60 發動機檢測報警項目表銷售維修保養零配件服務.康明斯QSK60 發動機檢測報警項目表想要更多的類型，請現在聯系湖南英珀威機械有限公司！
產品中心
康明斯QSK60 發動機檢測報警項目表
詳細描述
| POWER PLANT (MDE1) | LIST OF MONITORING & ALARM 檢測報警項目表 |
ZJC301-610-05 | TOT. 共 頁 | |||||||||||||||
| P. 第 頁 | ||||||||||||||||||
| No. 編號 |
Description 項目 |
Description(Chinese) 項目(中文) |
Kind 分類 |
Range 工作范圍 |
Set point 整定值 |
Dimension 單位 |
sig. 信號形式 |
Sensor NO. 傳感器編號 |
Suppression 抑制 |
Time delay 延時 |
Group alarm 報警分組 |
Function 功能 |
Supplier 供應者 |
Location 位置 |
Remarks (conn. to outstation NO.) 備 注 |
Checker (檢驗者) | ||
| Yard 船廠 |
BV 船檢 |
Own 船東 | ||||||||||||||||
| 601_101_PAL | MDE1 Low oil press | 低油壓 | 3.25 | bar | DI(NO) | PAL | KM | EN.RM | ||||||||||
| 601_101_PDT | MDE1 Fuel filter delta pressure | 燃油自清慮器壓力低 | 0.0174~0.348 | bar | DI(NC) | 061B1280 | PDT | CUM | EN.RM | |||||||||
| 601_101_PT | MDE1 Fuel filter outlet press | 燃油自清慮器出口壓力 | 0~1.6 | 0.7 | bar | 4-20mA | 060N1012 | 5 | PT | CUM | EN.RM | |||||||
| 601_101_SS | MDE1 Running at rated speed | 額定速度下運行指示 | 85~100 | ％ | DI(NC) | SS | CUM | EN.RM | ||||||||||
| 601_101_ST | MDE1 Engine Speed | 轉速指示 | 0~2200 | rpm | 4-20mA | 3408471 | ST | CUM | EN.RM | |||||||||
| 601_101_TAH | MDE1 Pre-High Engine Temp | 預高溫 | 94 | ℃ | DI(NC) | TAH | KM | EN.RM | START NEXT GENERATOR | |||||||||
| 601_101_TT | MDE1 Aftercooler Water Inlet Temperature | 后冷卻水進口溫度 | 0~150 | 71 | ℃ | PT100 | 131P081 | 10 | TT | CUM | EN.RM | |||||||
| 601_101_YS | MDE1Local/remote Status | 就地/遙控狀態 | DI(NO/NC) | YS | CUM | EN.RM | ||||||||||||
| 601_102_PAL | MDE1 Pre-Low Engine Oil Press | 預低油低 | 3 | bar | DI(NC) | PAL | KM | EN.RM | START NEXT GENERATOR | |||||||||
| 601_102_PT | MDE1 Lube oil pressure(LOW) | 滑油壓力 | 0~10 | bar | 4-20mA | 060N1054 | 5 | PT | CUM | EN.RM | ||||||||
| 601_102_TT | MDE1 Lube oil inlet temp(HIGH) | 滑油進口溫度 | -40~150 | 121 | ℃ | PT100 | 131P081 | 10 | TT | CUM | EN.RM | |||||||
| 601_102_XA | MDE1 Fail to start | 起動失敗 | DI(NC) | XA | CUM | EN.RM | ||||||||||||
| 601_102_YS_XYSP | MDE1 Stop command to engine | 遙控停止 | DO (Free) | YS | KM | EN.RM | ||||||||||||
| 601_103_PT | MDE1 Lube oil filter inlet for differential pressure | 滑油自清濾器進口壓力低 | 0~16 | 2.4 | bar | 4-20mA | 060G3127 | 5 | PT | CUM | EN.RM | |||||||
| 601_103_TT | MDE1 Charge air receiver temp, left bank rear | 左后掃氣箱進氣溫度 | -40~150 | 82 | ℃ | PT100 | 131P081 | 10 | TT | CUM | EN.RM | |||||||
| 601_103_XA | MDE1 Common warning (fault) | 公共報警 | DI(NC) | XA | CUM | EN.RM | ||||||||||||
| DG1LO.FITDIFFAL | 滑油壓差 | |||||||||||||||||
| 601_103_YS_XYST | MDE1 Remote Start | 遙控起動 | DO (Free) | YS | KM | EN.RM | ||||||||||||
| 601_104_PT | MDE1 Lube oil filter outlet for differential pressure | 滑油自清濾器出口壓力低 | 0~16 | 2.4 | bar | 4-20mA | 060G3127 | 5 | PT | CUM | EN.RM | |||||||
| 601_104_TT | MDE1 Charge air receiver temp, right bank rear | 右后掃氣箱進氣溫度 | -40~150 | 82 | ℃ | PT100 | 131P081 | 10 | TT | CUM | EN.RM | |||||||
| 601_104_XA | MDE1 Common Shutdown | 切斷報警 | DI(NC) | XA | CUM | EN.RM | ||||||||||||
| 601_105_PT | MDE1 Cylinder water inlet pressure or flow(LOW) | 缸套水進機壓力或流量 | 0~6 | 0.27 | bar | 4-20mA | 060N1053 | 5 | PT | CUM | EN.RM | |||||||
| 601_105_TT | MDE1 Charge air receiver temp, right bank front | 右前掃氣箱進氣溫度 | -40~150 | 82 | ℃ | PT100 | 131P081 | 10 | TT | CUM | EN.RM | |||||||
| 601_105_XA | MDE1 High Engine Temp | 溫度高 | 93 | ℃ | DI(NO) | XA | KM | EN.RM | ||||||||||
| 601_105_YS | MDE1 PRELUB OVERRIDE | 1號發電機預潤滑越控 | NC=OVERRIDE | DO (Free) | YS | CUM | EN.RM | |||||||||||
| 601_106_TT | MDE1 Cylinder cooling water outlet temp | 氣缸冷卻水出口溫度 | -50~150 | 97 | ℃ | 4-20mA | 131P081 | 10 | PT | CUM | EN.RM | |||||||
| 601_106_XA | MDE1 Overspeed | 超速 | 2003 | rpm | DI(NO) | XA | KM | EN.RM | ||||||||||
| 601_109_XA | MDE1 Shutdown for overspeed | 因超速而停止 | 2070 | rpm | DI(NO) | XA | CUM | EN.RM | ||||||||||
| 601_110_XA | MDE1 Shutdown for low lube press - low speed range | 低速時滑油壓力低停車 | 1.35 | bar | DI(NO) | XA | CUM | EN.RM | ||||||||||
| 601_111_XA | MDE1 Shutdown for low lube press - high speed range | 高速時滑油壓力低停車 | 2.9 | bar | DI(NO) | XA | CUM | EN.RM | ||||||||||
| 601_112_XA | MDE1 Shutdown for low coolant press | 因冷卻劑低壓停車 | 0.27 | bar | DI(NO) | XA | CUM | EN.RM | ||||||||||
| 601_113_XA | MDE1 Shutdown for high coolant temp | 因冷卻劑高溫停車 | 97 | ℃ | DI(NO) | XA | CUM | EN.RM | ||||||||||
| 601_114_XA | MDE1 Sensor fault | 傳感器故障 | DI(NO) | XA | CUM | EN.RM | ||||||||||||
| 601_115_XA | MDE1 Local panel power supply fault | 就地控制板電源單元故障 | DI(NO) | XA | CUM | EN.RM | ||||||||||||
| 601_122_TT | MDE1 Exhaust gas temp, left bank stack | 左廢氣溫度 | 0~800 | 593 | ℃ | 4-20mA | 3408543 | 5 | TT | CUM | EN.RM | |||||||
| 601_123_TT | MDE1 Exhaust gas temp, right bank stack | 右廢氣溫度 | 0~800 | 593 | ℃ | 4-20mA | 3408543 | 5 | TT | CUM | EN.RM | |||||||
| 651_101_UA | MG1 AVR FAILURE | 發電機AVR失敗報警 | DI(NO) | UA | CUM | EN.RM | ||||||||||||
| 651_101_TT | MG1 Winding temp phase V1 | V1相繞組溫度 | 130 | ℃ | PT100 | TT | CUM | EN.RM | ||||||||||
| 651_103_TT | MG1 Winding temp phase U1 | U1相繞組溫度 | 130 | ℃ | PT100 | TT | CUM | EN.RM | ||||||||||
| 651_105_TT | MG1Winding temp phase W1 | W1相繞組溫度 | 130 | ℃ | PT100 | TT | CUM | EN.RM | ||||||||||
| 651_107_TT | MG1 Bearing temp DE | 后軸承驅動端溫度 | 79 | ℃ | PT100 | TT | CUM | EN.RM | ||||||||||
| 651_108_TT | MG1 Bearing temp NDE | 后軸承非驅端溫度 | 79 | ℃ | PT100 | TT | CUM | EN.RM | ||||||||||
| 871_101_SSH | MDE1 Increment speed | 加速 | DO (Free) | SS | ABB | EN.RM | ||||||||||||
| 871_101_SSL | MDE1 Decrement speed | 減速 | DO (Free) | SS | ABB | EN.RM | ||||||||||||
